Solis S24 shuttle XL

VERSATILE PERFORMER

Treading acres with the toughest! The mighty SOLIS S24 Shuttle XL is manufactured to bring the best out of your ventures. Known for its intelligent ergonomics and heavy lifting capacity, this modern tractor is your way towards qualitative results.
ENGINE

MITSUBISHI ENGINE

Weight

HEAVIEST IN THE CATEGORY

Hydraulic Transmission

MANUAL DRIVE TRANSMISSION

100% Metal Hood Bonnet

100% METAL HOOD

Solis S24 Shuttle Xl
S24 Shuttle Xl Min

Digital Catalog

Powered by robotics and automation

Technical SPecifications

Engine Model Mitsubishi S3L2
HP Category 24 HP
No. of Cylinder 3
Aspiration Natural
Cubic Capacity (cc) 80.42
Rated RPM 2500
Max Torque 76.3 Nm@2000



Drive 4WD
Forward/Reverse Lever Synchromesh Shuttle Lever on Dashboard
Gearbox 9+9
Transmission Type Constant Mesh with Synchromesh Shuttle transmission
Cruise Control Yes
PTO (RPM) 540/540E
PTO Actuation Mechanical
Steering Power Steering

3 Point Linkages CAT1N
3 Point Lifting Capacity@ball ends (lbs) 1323
Hydraulic Rear Remotes 1DA (Detent with Float)
Total Hydraulic Flow
(GPM) Gallons Per Minute
6.5
Weight (lbs) 2513
Wheel Base (inches) 61.8
Total Length With TPL (inches) 113.98
Total Width (inches) 47.83
Height (inches) upto ROPS 91.53
Ground Clearance (inches) 9.44 (Front Axle)



IndustrialIndustrial 23×8.50-12 & 33×15.5-16.5
TurfTuff 23×8.50-12 & 33×15.5-16.5
TurfTuff 25×8.50-14 & 13.6×16
Agri TireAgriculture 6×12 & 8.3×20
Agri TireAgriculture 7×14 & 8.3×24
Radial GariRadial 6.5/80-12 & 280/70R 18
Galaxy ProGalaxy Pro 220/55 R12 & 280/70 R16



Type Oil Immersed Brakes
Type of Actuation Mechanical, Foot Operated
Differential Lock Standard
Fuel Tank (Gal) 5.8

Major Applications

These smart, compact tractors are designed to provide perfection in every venture and are highly useful in various applications. The powerful and fuel-efficient engine enables grass-cutting and loader applications with ease. Whether it is about clearing the snow with extra efficiency or leveling the path to success, S24 Shuttle XL delivers agile performance in every aspect.
